Product Details
Bridge lifting
Combined with the belly-lifting cylinder, the bridge body is lifted synchronously for bearing replacement.
Heavy installation
Positioning of large-tonnage equipment in a narrow space (such as boiler installation in a power plant).
Emergency rescue
Rapidly lift the collapsed structure and cooperate with rescue operations.
Features
1. Designed in coordination with the belly-lifting cylinder
Designed to match the belly-lifting cylinder structure optimization, the thrust of the cylinder is amplified through the lever principle to achieve a higher load capacity (up to hundreds of tons), and the horizontal thrust of the cylinder is converted into a vertical lifting force, which improves work efficiency and saves installation space.
2. High-strength material and structure
Adopting high-quality alloy steel welding, it has strong pressure resistance and deformation resistance, ensuring the safety of long-term heavy-duty operations. Modular design supports multiple groups of parallel use to meet different engineering needs.
3. Precise displacement control
Cooperating with the hydraulic system of the belly-lifting cylinder, it achieves millimeter-level lifting accuracy, which is suitable for high-precision operations such as bridge jacking and equipment calibration.
4. Safe and reliable
Built-in self-locking device to prevent sudden fall when oil pressure fails; surface anti-rust treatment to adapt to harsh outdoor environments.
